If you are looking to replace your Power Window Motor on your Acadia, Aura, Enclave or G6 Cardone offers top quality remanufactured affordable replacement that matched your oem parts quality.
FITMENT CHART
Please wait...
Please wait...
Please wait...
Please wait...
Please wait...
Please wait...
Please wait...
Please wait...
Please wait...
Please wait...
INTERCHANGE
Chevrolet : 15781321
Chevrolet : 25783494
Chevrolet : 15781318
Chevrolet : 20774637
Chevrolet : 15208670
Chevrolet : 15843328
Chevrolet : 10385194
Chevrolet : 22683759
Chevrolet : 15263123
Chevrolet : 15781322
Chevrolet : 15869735
Chevrolet : 21995321
Chevrolet : 10385197
Chevrolet : 25783492
Chevrolet : 25797228
Chevrolet : 15208673
Chevrolet : 15781325
Chevrolet : 22683752
Chevrolet : 25943967
General Motors : 22683752
General Motors : 15781325
General Motors : 10385197
General Motors : 25797228
General Motors : 15208670
General Motors : 15263123
General Motors : 15263126
General Motors : 15781318
General Motors : 15781322
General Motors : 10377079
General Motors : 15781321
General Motors : 25783492
General Motors : 10385194
General Motors : 15208673
General Motors : 15869735
General Motors : 22683759
General Motors : 25783494
General Motors : 25810429
General Motors : 15861473
General Motors : 15843328
General Motors : 15912785
General Motors : 20774637
General Motors : 21995321
Buick : 15208670
Buick : 15208673
Buick : 25783494
Buick : 25797228
Buick : 15263123
Buick : 25783492
Buick : 15843328
Buick : 15781325
Buick : 20774637
Buick : 10385197
Buick : 21995321
Buick : 22683752
Buick : 10385194
Buick : 22683759
Hummer : 10385194
Hummer : 15263123
Hummer : 22683759
Hummer : 10377079
Hummer : 21995321
Hummer : 15208670
Hummer : 15208673
Hummer : 22683752
Hummer : 20774637
Hummer : 25797228
Hummer : 10385197
Hummer : 15781325
Hummer : 15843328
Hummer : 15869735
Saturn : 10385197
Saturn : 20774637
Saturn : 21995321
Saturn : 25783492
Saturn : 25797228
Saturn : 15208673
Saturn : 15263123
Saturn : 25783494
Saturn : 15208670
Saturn : 22683752
Saturn : 15781322
Saturn : 22683759
Saturn : 15781325
Saturn : 15843328
Saturn : 10385194
Saturn : 15869735
Pontiac : 15781325
Pontiac : 15843328
Pontiac : 20774637
Pontiac : 21995321
Pontiac : 25797228
Pontiac : 15263123
Pontiac : 10385197
Pontiac : 15263126
Pontiac : 10385194
Pontiac : 15208670
Pontiac : 15208673
Pontiac : 25810429
Pontiac : 15861473
Pontiac : 15912785
Pontiac : 22683752
Pontiac : 22683759
SPECIFICATIONS
First Application Year
2004
Package Contents
Window Lift Motor, Instruction Sheet
Product Condition
Remanufactured
Mounting Hole Quantity
3
Mounting Type
Through Hole
Gear Included
Yes
Window Motor Use Location
Rear Left; Front Right; Front Left
Regulator Included
No
E-Waste
Yes
Wire Quantity
2
FAQs
A motor equipped with an anti-pinch safety feature typically has 5 or more terminals or pins as well as an express-up feature on the window switch.
FAQs
An external module monitors the rotation of the internal gear. If there is a change in the pulse train of the sensor before the window if fully closed, the module will interpret this change as something preventing the window from moving easily, which causes the module to change polarity to the motor to reverse its direction.
FAQs
Can I bench-test a case grounded motor?
FAQs
Do all vehicles with power windows have an anti-pinch safety feature?
FAQs
Dry or worn weather-strip and tracks, dirty switch contacts, or damaged window regulator could be causing these problems.
FAQs
How can I tell if my vehicle has an anti-pinch window lift motor?
FAQs
How does the anti-pinch safety feature work?
FAQs
Is it necessary to reset a motor that has the anti-pinch safety feature after installation?
FAQs
Most 2-terminal or 2-wire motors are grounded through the control switch; however, some older applications use the motor housing as a common ground. If power supply and ground are applied directly to the terminals of a motor with this design, an internal short may result. These motors require a battery ground be directly applied to the housing, and then power can be applied to either terminal.
FAQs
My window drops 2 to 3 inches from the upper window channel, then stops when I use the “Auto-Up” feature in my Toyota or Nissan. What’s causing this?
FAQs
Noisy operation or a popping sound can be misdiagnosed as a window lift motor problem. What may actually be happening is the regulator cable hold-down may be broken or missing; this would allow the cable to snag on the window regulator bracket as the window is raised, producing the noise. Install a new hold-down or suitable substitute.
FAQs
Not if the motor is installed and is not disturbed from its factory-set position. If the motor is operated before being coupled to regulator, then it will need to be reset.
FAQs
The anti-pinch feature was introduced by Opel in 1986. Most vehicles built after 2008 with an auto-up and auto-down switch option have an anti-pinch safety feature.
FAQs
The anti-pinch safety feature prevents the window glass from reaching the end of its upward travel when the system senses an obstacle in the path of the glass.
FAQs
The likely cause is a window lift motor that was bench-tested or operated before being installed into the window regulator. This action cancels the upper limit position. All express up/down motors are shipped in the “full up” position and should not be bench-tested until fully coupled with the regulator. If disturbed, the motor’s travel limits must be set for the motor to know whether the window is closed or open. Follow the correct procedure as stated in a vehicle specific service manual or web-based tutorial to set travel limits.
FAQs
The vehicle may have faulty wiring or a defective control switch. Most 2-wire window lift motors depend on a voltage polarity change to control direction. If the motor runs in one direction but not the other, the problem is most likely in the wiring or switch. On some older GM applications, the ground is always applied to the motor body, with direction switching being controlled by whichever of the two pins receives voltage.
FAQs
What are the advantages of Phenolic pistons over steel?
FAQs
What causes noisy operation or popping on a window lift motor with a cable-type regulator design?
FAQs
What’s an anti-pinch safety feature?
FAQs
Why does my 2-wire window lift motor only run in one direction?
Features and Benefits
As a remanufactured Original Equipment part, this unit guarantees a perfect vehicle fit.
Features and Benefits
Each motor is 100% tested. Testing includes loading the motor on a simulated window fixture to verify speed and strength of the motor
Features and Benefits
Every motor has its internal components inspected and gauged. Bushings are gauged and re-impregnated with lubricating oil, ball bearings are replaced with new and armatures are fully tested to ensure insulation
Features and Benefits
Every remanufactured motor is assembled with the precise amount of lubricant to ensure quiet operation and long life
Features and Benefits
Every remanufactured motor is fully compatible with the O.E. mounting and regulator
Features and Benefits
For motors which have an auto up / down feature, output signals and pulse counts are matched to the vehicle application and motors are shipped in the ‘full up position’
Features and Benefits
Internal gears are gauged, inspected and renewed for reuse or replaced if out of spec. Replacement gears are redesigned with a stronger, less brittle material than O.E. to prevent premature wear, stripping and breakage
Features and Benefits
Motor magnets are 100% recharged, guaranteeing efficiency and reliability
Features and Benefits
Our remanufacturing process is earth-friendly, as it reduces the energy and raw material needed to make a new part by 80%.
CARDONE® Remanufactured Window Lift Motors are direct-fit O.E. replacements that began as Original Equipment cores. Each unit is re-engineered, renewed and tested to match O.E. performance. For nearly half a century, CARDONE Remanufactured Window Lift Motors have provided rock-solid reliability that you can trust for the long haul.
