If you are looking to replace your Power Window Motor on your Acadia, Aura, Enclave or G6 Cardone offers top quality remanufactured affordable replacement that matched your oem parts quality.
FITMENT CHART
Please wait...
Please wait...
Please wait...
Please wait...
Please wait...
Please wait...
Please wait...
Please wait...
Please wait...
Please wait...
Please wait...
INTERCHANGE
Chevrolet : 15269139
Chevrolet : 15781319
Chevrolet : 25709966
Chevrolet : 25709967
Chevrolet : 25783494
Chevrolet : 10385196
Chevrolet : 15781320
Chevrolet : 25943968
Chevrolet : 15869735
Chevrolet : 25783492
Chevrolet : 25783493
Chevrolet : 15269138
Chevrolet : 25783495
Chevrolet : 15781323
Chevrolet : 15208673
Chevrolet : 15263126
Chevrolet : 15277661
Chevrolet : 15869734
Chevrolet : 22683759
Chevrolet : 25797227
Chevrolet : 10385197
Chevrolet : 15208671
Chevrolet : 15781321
Chevrolet : 15843329
Chevrolet : 22683758
Chevrolet : 15208672
Chevrolet : 20774636
Chevrolet : 15781324
General Motors : 15781321
General Motors : 25783492
General Motors : 25797227
General Motors : 10377078
General Motors : 15843329
General Motors : 10385196
General Motors : 15218845
General Motors : 15277661
General Motors : 15781320
General Motors : 15208671
General Motors : 15269139
General Motors : 15781323
General Motors : 22683758
General Motors : 10385197
General Motors : 15269138
General Motors : 25709966
General Motors : 15263125
General Motors : 15263126
General Motors : 15869734
General Motors : 15869735
General Motors : 22683759
General Motors : 25709967
General Motors : 25783495
General Motors : 15912786
General Motors : 25783494
General Motors : 15208672
General Motors : 15208673
General Motors : 20774636
General Motors : 15781319
General Motors : 25783493
Buick : 10385196
Buick : 15263126
Buick : 25709967
Buick : 25783492
Buick : 15208671
Buick : 15269138
Buick : 15208673
Buick : 15869735
Buick : 22683759
Buick : 25783494
Buick : 15269139
Buick : 25783495
Buick : 15277661
Buick : 25709966
Buick : 20774636
Buick : 15208672
Buick : 10385197
Buick : 15781321
Buick : 25783493
Buick : 25797227
Buick : 22683758
Cadillac : 10385197
Cadillac : 15263126
Cadillac : 15269138
Cadillac : 15269139
Cadillac : 20774636
Cadillac : 25709966
Cadillac : 25783492
Cadillac : 25797227
Cadillac : 15208672
Cadillac : 15208673
Cadillac : 15218845
Cadillac : 15781321
Cadillac : 22683759
Cadillac : 25783494
Cadillac : 15277661
Cadillac : 25709967
Cadillac : 10385196
Cadillac : 22683758
Cadillac : 15208671
Cadillac : 15869735
Hummer : 15269138
Hummer : 15269139
Hummer : 25709967
Hummer : 15869735
Hummer : 20774636
Hummer : 15277661
Hummer : 25709966
Hummer : 25783492
Hummer : 10377078
Hummer : 15208672
Hummer : 10385197
Hummer : 15208671
Hummer : 15263126
Hummer : 22683758
Hummer : 25797227
Hummer : 15208673
Hummer : 15781321
Hummer : 22683759
Hummer : 10385196
Hummer : 25783494
Saturn : 15263126
Saturn : 22683759
Saturn : 15269138
Saturn : 15869734
Saturn : 15869735
Saturn : 25783494
Saturn : 10385197
Saturn : 15269139
Saturn : 15277661
Saturn : 22683758
Saturn : 15781321
Saturn : 10385196
Saturn : 15208672
Saturn : 25783493
Saturn : 25797227
Saturn : 15208673
Saturn : 20774636
Saturn : 25709966
Saturn : 25709967
Saturn : 25783495
Saturn : 15208671
Saturn : 15781323
Saturn : 25783492
Pontiac : 15269138
Pontiac : 15269139
Pontiac : 15912786
Pontiac : 10385197
Pontiac : 15263125
Pontiac : 15869735
Pontiac : 20774636
Pontiac : 25709967
Pontiac : 25709966
Pontiac : 15208671
Pontiac : 25783492
Pontiac : 10385196
Pontiac : 15208673
Pontiac : 15263126
Pontiac : 22683758
Pontiac : 15208672
Pontiac : 15277661
Pontiac : 25797227
Pontiac : 15781321
Pontiac : 22683759
Pontiac : 25783494
SPECIFICATIONS
Mounting Type
Through Hole
Features and Benefits
Every remanufactured motor is fully compatible with the O.E. mounting and regulator
Features and Benefits
Our remanufacturing process is earth-friendly, as it reduces the energy and raw material needed to make a new part by 80%.
FAQs
Why does my 2-wire window lift motor only run in one direction?
FAQs
How can I tell if my vehicle has an anti-pinch window lift motor?
Gear Included
Yes
FAQs
The likely cause is a window lift motor that was bench-tested or operated before being installed into the window regulator. This action cancels the upper limit position. All express up/down motors are shipped in the “full up” position and should not be bench-tested until fully coupled with the regulator. If disturbed, the motor’s travel limits must be set for the motor to know whether the window is closed or open. Follow the correct procedure as stated in a vehicle specific service manual or web-based tutorial to set travel limits.
Features and Benefits
Each motor is 100% tested. Testing includes loading the motor on a simulated window fixture to verify speed and strength of the motor
Features and Benefits
Motor magnets are 100% recharged, guaranteeing efficiency and reliability
FAQs
My window drops 2 to 3 inches from the upper window channel, then stops when I use the “Auto-Up” feature in my Toyota or Nissan. What’s causing this?
FAQs
What are the advantages of Phenolic pistons over steel?
FAQs
Dry or worn weather-strip and tracks, dirty switch contacts, or damaged window regulator could be causing these problems.
E-Waste
Yes
Mounting Hole Quantity
3
Product Condition
Remanufactured
FAQs
Is it necessary to reset a motor that has the anti-pinch safety feature after installation?
FAQs
The vehicle may have faulty wiring or a defective control switch. Most 2-wire window lift motors depend on a voltage polarity change to control direction. If the motor runs in one direction but not the other, the problem is most likely in the wiring or switch. On some older GM applications, the ground is always applied to the motor body, with direction switching being controlled by whichever of the two pins receives voltage.
Wire Quantity
2
FAQs
An external module monitors the rotation of the internal gear. If there is a change in the pulse train of the sensor before the window if fully closed, the module will interpret this change as something preventing the window from moving easily, which causes the module to change polarity to the motor to reverse its direction.
Features and Benefits
Internal gears are gauged, inspected and renewed for reuse or replaced if out of spec. Replacement gears are redesigned with a stronger, less brittle material than O.E. to prevent premature wear, stripping and breakage
Features and Benefits
Every remanufactured motor is assembled with the precise amount of lubricant to ensure quiet operation and long life
FAQs
Not if the motor is installed and is not disturbed from its factory-set position. If the motor is operated before being coupled to regulator, then it will need to be reset.
FAQs
Can I bench-test a case grounded motor?
FAQs
What causes noisy operation or popping on a window lift motor with a cable-type regulator design?
FAQs
The anti-pinch safety feature prevents the window glass from reaching the end of its upward travel when the system senses an obstacle in the path of the glass.
Features and Benefits
As a remanufactured Original Equipment part, this unit guarantees a perfect vehicle fit.
FAQs
Do all vehicles with power windows have an anti-pinch safety feature?
Package Contents
Window Lift Motor, Instruction Sheet
First Application Year
2004
Features and Benefits
Every motor has its internal components inspected and gauged. Bushings are gauged and re-impregnated with lubricating oil, ball bearings are replaced with new and armatures are fully tested to ensure insulation
FAQs
How does the anti-pinch safety feature work?
FAQs
Noisy operation or a popping sound can be misdiagnosed as a window lift motor problem. What may actually be happening is the regulator cable hold-down may be broken or missing; this would allow the cable to snag on the window regulator bracket as the window is raised, producing the noise. Install a new hold-down or suitable substitute.
Window Motor Use Location
Rear Right; Front Right; Front Left
FAQs
Most 2-terminal or 2-wire motors are grounded through the control switch; however, some older applications use the motor housing as a common ground. If power supply and ground are applied directly to the terminals of a motor with this design, an internal short may result. These motors require a battery ground be directly applied to the housing, and then power can be applied to either terminal.
FAQs
The anti-pinch feature was introduced by Opel in 1986. Most vehicles built after 2008 with an auto-up and auto-down switch option have an anti-pinch safety feature.
FAQs
What’s an anti-pinch safety feature?
Features and Benefits
For motors which have an auto up / down feature, output signals and pulse counts are matched to the vehicle application and motors are shipped in the ‘full up position’
Regulator Included
No
FAQs
A motor equipped with an anti-pinch safety feature typically has 5 or more terminals or pins as well as an express-up feature on the window switch.
CARDONE® Remanufactured Window Lift Motors are direct-fit O.E. replacements that began as Original Equipment cores. Each unit is re-engineered, renewed and tested to match O.E. performance. For nearly half a century, CARDONE Remanufactured Window Lift Motors have provided rock-solid reliability that you can trust for the long haul.
